15L High-Efficiency Disc-Type Sand Mill Bead Mill Machine
Definition and Uses of Beading Mill Machine
A bead mill machine, also known as a bead mill or a sand mill, is a
specialized grinding and dispersing machine used in various
industries for the particle size reduction and dispersion of
materials. It is particularly effective in the wet grinding and
dispersion of solid particles or agglomerates in a liquid medium.
The bead mill machine consists of a cylindrical chamber or vessel
filled with grinding beads, typically made of glass, ceramics, or
steel. The materials to be processed are introduced into the
chamber along with the liquid medium. The rotation of a central
shaft or agitator causes the beads to collide and agitate the
material, resulting in the grinding or dispersion of particles.
The grinding beads inside the chamber provide the grinding action
by exerting mechanical force on the material, effectively reducing
the particle size. The design of the bead mill allows for efficient
grinding and dispersion while minimizing heat generation and
contamination.
Bead mill machines are widely used in industries such as paint,
ink, coatings, pigments, dyes, pharmaceuticals, cosmetics, and food
processing. They can be used for various applications, including
fine grinding, micronization, homogenization, and dispersion of
materials.
It's important to note that bead mill machines may have different
configurations and features depending on the specific application
and desired particle size requirements. Additionally, proper
maintenance and cleaning procedures should be followed to ensure
optimal performance and prevent cross-contamination when processing
different materials.
Advantages of Sanding Machine
Sanding machines offer several advantages:
1. High Efficiency: Sanding machines enable fast and efficient
material grinding and polishing, thereby improving production
efficiency.
2. Versatility: Sanding machines are suitable for various types of
materials, including metals, wood, glass, and stone, making them
widely applicable in different industries.
3. Precision: Sanding machines allow for precise control of the
machining process, resulting in improved surface smoothness and
accuracy.
4. Surface Quality: By using a sanding machine, the surface quality
of materials can be enhanced by removing unevenness, scratches,
oxide layers, and coatings.
5. Adjustability: Sanding machines typically have adjustable
grinding parameters such as abrasive particle size and wheel speed,
allowing for customization to achieve desired machining effects.
6. Automation: Advanced sanding machines are equipped with
automation control systems, enabling automated machining operations
and enhancing production efficiency and precision.
In summary, sanding machines play a crucial role in various
machining fields, offering efficient, precise, and versatile
material processing capabilities that lead to improved product
quality and increased production efficiency.
ZM-T Series:
| Type | ZM8-T | ZM18-T | ZM25-T | ZM60-T |
| Grinding chamber volume (l) | 8 | 18 | 25 | 60 |
| Batch size (l) | 100-1500 | 300-2500 | 400-3000 | 500-6000 |
| Drive (kW) | 18.5-22 | 37-45 | 45-55 | 75-90 |
| Length (mm) | 1400 | 1800 | 1900 | 2300 |
| Width (mm) | 800 | 1050 | 1050 | 1250 |
| Height (mm) | 1700 | 1900 | 1900 | 2150 |
| Weight (kg) | 900 | 1800 | 2000 | 3600 |
| Note: Technical data are different if there are some customized
constructions. |
