100L Wet Grinding Machine Disc Grinder Sand Mill For Paint

Wet Grinding for Particle Size Reduce Degold 100 Liters Zm-X Horizontal Bead Mill ISO9001


DEGOLD ZM-X series horizontal bead mill is a kind of wet-grinding machine to dispersing low, medium and high viscosity materials. The special designed dispersion discs, appropriate grinding bead, and the functional mechanical seals ensure the effective of the DEGOLD ZM-X series horizontal bead mill.
Customers can choose the diameter of the bead, the material of the dispersing shaft, dispersing discs to improve the quality of your products. We have many models, and the effective volume from 5L to 200L. In a word, we will choose the best one for you according to your producing formulation.
Degold 100 Liters Zm-X Horizontal Bead Mill
Principle of Operation: The rotary grinding shaft drives all grinding mediums inside the grinding chamber. The grinding mediums passes the powers to the materials to reduce the particle size. Gap separator inside the horizontal bead mills separates the products and the grinding mediums. They are suitable for different viscosities formulations.
ZM100-X horizontal bead mill (100liters)
1) 100 Liters,
2) Suitable for zirconia grinding beads,
3) Mechanical seal, (single mechanical seal and double mechanical seal for option)
4) Explosive proof for solvent based formulation/non explosive proof for water based formulation.
5) Hard alloy griniding chamber and grinding discs. Different materials for grinding chamber and grinding discs for option.
6) Double-diaphragm fluid transfer pump,
7) With/without AC drive to control grinding shaft rotary speeds.
Application:
Degold 100 Liters Zm-X Horizontal Bead Mill
There are the others construction ways and materials for 100 liters, please contact with us to get suitable model for your productions. Thanks.
Production Line:
Degold 100 Liters Zm-X Horizontal Bead Mill
ZM-X Series Disc Type Bead Mill Technical Data Sheet:

Model

ZM5-XZM15-XZM20-XZM30-XZM50-XZM100-XZM200-X

Effective grinding chamber volume (L)

515203050100200
Main motor power (kW)1118.5223037/4545/5555/75
Grinding shaft rotary speed (r/min)1650120012001120900700550
Adjustable range of materials flow (L/min)0~20~20~100~100~600~600~150
Max. cooling water consumption (t/h)11222.52.53~4
Estimated productivity (kg/h)15~15040~40050~50060~800150~1500150~1500200~2000
Dimension (mm)
Length1250156016701760197021752150
Width900105010501050115012001200
Height1250155015651585165018802150
Net weight (kg)70080010001150135020002500

CE Certificate:
Degold 100 Liters Zm-X Horizontal Bead Mill
Exhibition:
Degold 100 Liters Zm-X Horizontal Bead Mill

Customers Layout:

Degold 100 Liters Zm-X Horizontal Bead Mill
